Technical parameters:
1.Rated voltage:220V-240V/110V-120V
2.Frequency:50/60Hz
3.Max. current:10A
4.Max. power:1.1kW
5.Start pressure setting: 1.2bar,1.5bar,2.2bar
6.Max working pressure:10bar
7.Joint Screw:1"
8.Grade of protection:IP65
9.Max working temperature:60℃

Function:
1.Start and stop the pump automatically
2.Protect the pump from damage caused by dry-running
3.Protect the pump from damage caused by dry-overheat
4.Examine the water automatically
5.Forced start

PACKAGE

PACKING SIZE(M3)	PCS/CNT	N.W(KGS)	G.W(KGS)	20＇GP
54×44.5×33(cm)	12	14.5	16.5	4320PCS/360CTNS
